DIOT SCADA with MQTT
DIOT which stands for Decoupled IOT, has its SCADA functionalities decoupled into Host and Node for flexibility and scalability that catered for IoT era. This plugin functions as the SCADA Host to work with your device or system, which will be treated as SCADA Node.
The supported IoT protocol is MQTT. You just need to enter the MQTT broker/server into the configuration. You may then subscribe to the desired topic with a shortcode to display in any desired web page or post.
[diot topic="building/floor/device/sensor"]
Or, if you have a JSON content, you may add dollar sign as JSON root:
[diot topic="building/floor/device/sensor$json.data"]
The content will be updated dynamically when the device publish any data.
You may also choose to display your realtime data in trending chart. Check out Ecava DIOT online demo to see how easy things can be done now!
Download & install the zip archive
The plugin package installer can be downloaded from the WP2E project tab called “code”.
1 – Select the version to download if this option is available otherwise the “latest” version of the main plugin will be used.
2 – After downloading the zip archive install the plugin package installer in you local environment and activate the script from the plugin list.
3 – Under the section “Plugins” of the admin dashboard you should see a new “Dependencies & Licenses” link. Follow the instructions from this panel to finalize the installation of the missing dependencies.
-
- Give a name to your project
-
- Download the Installer Package
-
- Install & activate the plugin locally
-
- Install the suggested dependencies
Tips: Use the WP2E panel to add/suggest new dependencies to the local installation. Press F5 in the list of dependencies if the changes are not displayed right away.
