Music Sheet Viewer
« Music Sheet Viewer » allows you to display a digital music sheet by just entering its code using the shortcode tag [pn_msv], of with Block editor, through a « Music Sheet Viewer » dedicated block.
The supported music sheet formats are MusicXML (incl. compressed mxl files), MEI, ABC or PAE (RISM notation). The score is displayed as if it had been natively supported by the browser.
You do not need to escape HTML entities or anything. Just post your code as-is, even if the code is an XML dialect. The plugin will handle the rest.
The score is resized automatically so as to fit to the available content, you can specify the music font in which the score will be rendered and you can get the music code from a file if you don’t want to write the code inline.
You can play the score and there’s even an option to highlight the notes as they are played!
This plugin supports multi-pages scores and when played, the pages are turned automatically.
With this plugin, never ever upload a music sheet image to your website that is not zoomable and requires a new upload every time a single note must be changed!!!
At last, it’s fully responsive!
For a complete documentation of the plugin, see this plugin’s homepage..
Shortcode
Just wrap your music sheet code inside [pn_msv] shortcode, such as :
[pn_msv format="abc"]
X:1
T:La Vie En Rose
M:C|2
L:1/4
K:C
c3B|AGEc|B3A|GECB|A3G|EB,CB|A4|G2z2|]
[/pn_msv]
(ABC code example), and the corresponding score will be rendered.
You do not need to escape HTML entities or anything, just post your code as-is. The plugin will handle the rest.
Complete details of the different Music Sheet formats supported and possible shortcode/block
parameters are described at this plugin’s homepage..
Related Links
Download & install the zip archive
The plugin package installer can be downloaded from the WP2E project tab called “code”.
1 – Select the version to download if this option is available otherwise the “latest” version of the main plugin will be used.
2 – After downloading the zip archive install the plugin package installer in you local environment and activate the script from the plugin list.
3 – Under the section “Plugins” of the admin dashboard you should see a new “Dependencies & Licenses” link. Follow the instructions from this panel to finalize the installation of the missing dependencies.
-
- Give a name to your project
-
- Download the Installer Package
-
- Install & activate the plugin locally
-
- Install the suggested dependencies
Tips: Use the WP2E panel to add/suggest new dependencies to the local installation. Press F5 in the list of dependencies if the changes are not displayed right away.
